CARVESMART™ Clamp Assemblies

ROEMHELD Precision Vises

Save to My Project

What is this?

Product Information

CARVESMART™ Clamp Assemblies Part # CLR-80003 Carr Lane Mfg.®

CARVESMART replaces cap-screw-attached jaws with dovetailed jaws held by these powerful clamping elements conveniently accessed from the top of the master jaw. Vises no longer have to be opened to access the face-mounted cap screws. A Differential Speed Screw positively drives the clamp up and down at twice the rate of a cap screw, and holds it positively retracted for jaw changes.

A set of these clamp assemblies is included with each Master Jaw.

View in Catalog Page
Contact Customer Service
Contact Customer Service

Differential Speed Screw

Diagram showcasing the application of Carvesmart Clamp Assemblies

Material

Alloy steel, black oxide finish.

Click here for detailed material and finish specifications.

CARVESMART™ Clamp Assemblies

Complete Clamp Assembly

Includes Differential Speed Screw

QUANTITY	PART NO.	THREAD	FOR MASTER JAWS
	CLR-80005	5/16-24	100mm and 4" (2 required per jaw) 125mm, 5", and 6" (3 required per jaw)
	CLR-80006	3/8-24	160mm and 8" (3 required per jaw)

Check Price & Availability

Legend:

Get More Information
Download CAD Model
New Product
E Exclusive Product
Quick Ship Available

Check Price & Availability

Legend:

Get More Information
Download CAD Model
New Product
E Exclusive Product

Differential Speed Screw Only

QUANTITY	PART NO.	THREAD	FOR MASTER JAWS
	CLR-80003	5/16-24	100mm and 4" (2 required per jaw) 125mm, 5", and 6" (3 required per jaw)

Check Price & Availability

Legend:

Get More Information
Download CAD Model
New Product
E Exclusive Product
Quick Ship Available

Check Price & Availability

Legend:

Get More Information
Download CAD Model
New Product
E Exclusive Product
