Chip-Breaker Bushings – Metric (CHM)

Drill Bushings

 Save to My Project
What is this?

8mm OD
QUANTITY PART NO. ID (mm) OD (mm) LENGTH (mm) F DIA (mm) G (mm) H (mm) J (mm) L R (mm) LOCKSCREW
CHM-8-10-1.00 1.00 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.00 1.00 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.05 1.05 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.05 1.05 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.10 1.10 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.10 1.10 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.15 1.15 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.15 1.15 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.20 1.20 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.20 1.20 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.25 1.25 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.25 1.25 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.30 1.30 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.30 1.30 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.35 1.35 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.35 1.35 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.40 1.40 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.40 1.40 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.45 1.45 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.45 1.45 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.50 1.50 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.50 1.50 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.55 1.55 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.55 1.55 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.60 1.60 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.60 1.60 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.65 1.65 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.65 1.65 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.70 1.70 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.70 1.70 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.75 1.75 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.75 1.75 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.80 1.80 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.80 1.80 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.85 1.85 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.85 1.85 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.90 1.90 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.90 1.90 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-1.95 1.95 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-1.95 1.95 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.00 2.00 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.00 2.00 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.05 2.05 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.05 2.05 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.10 2.10 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.10 2.10 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.15 2.15 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.15 2.15 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.20 2.20 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.20 2.20 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.25 2.25 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.25 2.25 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.30 2.30 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.30 2.30 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.35 2.35 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.35 2.35 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.40 2.40 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.40 2.40 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.45 2.45 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.45 2.45 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.50 2.50 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.50 2.50 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.55 2.55 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.55 2.55 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.60 2.60 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.60 2.60 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.65 2.65 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.65 2.65 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.70 2.70 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.70 2.70 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.75 2.75 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.75 2.75 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.80 2.80 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.80 2.80 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-2.90 2.90 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-2.90 2.90 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.00 3.00 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.00 3.00 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.10 3.10 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.10 3.10 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.20 3.20 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.20 3.20 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.25 3.25 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.25 3.25 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.30 3.30 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.30 3.30 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.40 3.40 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.40 3.40 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.50 3.50 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.50 3.50 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.60 3.60 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.60 3.60 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.70 3.70 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.70 3.70 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.75 3.75 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.75 3.75 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.80 3.80 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.80 3.80 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-3.90 3.90 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-3.90 3.90 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-10-4.00 4.00 8 10 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
CHM-8-16-4.00 4.00 8 16 15 6 3 4.5 65° 11.5 LSM-1 or LSM-2
